Quantronix CUBISCAN 325 User Manual

COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 60
41
Cubiscan/Host
originated
Alpha (C/H) 43h or 48h
5 6 Location identifier Alpha 000000-ZZZZZZ
11 1 Comma Alpha (,) 2Ch
12 1 Length identifier Alpha (L) 4C
13 5
Length Numeric
00.00 - 99.99
1
18 1 Comma Alpha (,) 2Ch
19 1 Width identifier Alpha (W) 57h
20 5
Width Numeric
00.00 - 99.99
1
25 1 Comma Alpha (,) 2Ch
26 1 Height identifier Alpha (H) 48h
27 5
Height Numeric
00.00 - 99.99
1
32 1 Comma Alpha (,) 2Ch
33 2 Dimension unit Alpha (in/cm) 45h or 4Dh
35 1 Weight identifier Alpha (K) 4Bh
36 6
Weight Numeric
00.000 - 99.999
2
42 1 Comma Alpha (,) 2Ch
43 1 Dim. wgt. identifier Alpha (D) 44h
44 6
Dim. weight Numeric
000.00-999.99
1
50 1 Comma Alpha (,) 2Ch
51 2 Wgt./Dim. wgt unit Alpha (lb/kg)
53 1 Factor identifier Alpha (F) 46h
54 4 Factor Numeric 0000-9999
58 1 Comma Alpha (,) 2Ch
59 1 Domestic/Int'l. unit Alpha (D/I) 44h or 49h
60 1 End of text Control (ETX) 03h
61 1 Carriage return Control (CR) 0Dh
62 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Measure command Alpha (M) 4Dh
3 1 Neg. acknowledge Alpha (N) 4Eh
41
Cubiscan/Host
originated
Alpha (C/H) 43h or 48h
51
Measure/Zero error Alpha (M/Z) 43h or 4Dh
or 5Ah
Pos Len Description Type Range ASCII

Quantronix CUBISCAN 325 Specifications

General

Brand	Quantronix
Model	CUBISCAN 325
Category	Accessories
Language	English
