COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 61
Identification/Serial number
This command causes the Cubiscan 325 to change its current serial number data field. The serial
number is an eight-digit code which uniquely identifies the Cubiscan 325.
6 1 End of text Control (ETX) 03h
7 1 Carriage return Control (CR) 0Dh
8 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 ID Serial # command Alpha (I) 49h
38
Serial number Numeric 00000000-
99999999
11 1 End of text Control (ETX) 03h
12 1 Carriage return Control (CR) 0Dh
13 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 ID Serial # command Alpha (I) 49h
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 ID Serial # command Alpha (I) 49h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
