COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 67
Scale reading
This command causes the Cubiscan 325 to report the measured weight of objects on the scale.
This can be used to verify if the scale is empty.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Build command Alpha (s) 673h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Build command Alpha (s) 73h
3 1 Acknowledge Alpha (A) 41h
4 1 Weight identifier Alpha (K) 4Bh
5 6 Weight Numeric 00.000-99.999
11 1 Comma Alpha (,) 2Ch
12 2 Wgt. Dim. wgt unit Alpha (lb/kg)
14 1 End of text Control (ETX) 03h
15 1 Carriage return Control (CR) 0Dh
16 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Build command Alpha (s) 73h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
