COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 71
Smallest box mode
This command causes the Cubiscan 325 to calculate measurements based on the smallest box.
3 1 Acknowledge Alpha (4) 34h
4 4 Index Numeric (0000-9999)
8 1 End of text Control (ETX) 03h
9 1 Carriage return Control (CR) 0Dh
10 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Serial put command Alpha (p) 70h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Smallest box command Alpha (j) 6Ah
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Smallest box command Alpha (j) 6Ah
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Smallest box command Alpha (j) 6Ah
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
Pos Len Description Type Range ASCII
