COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 73
Units
This command causes the Cubiscan 325 to report its current unit settings, dimensional factor,
and location ID.
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Values command Alpha (U) 55h
3 1 End of text Control (ETX) 03h
4 1 Carriage return Control (CR) 0Dh
5 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Units command Alpha (U) 55h
3 1 Acknowledge Alpha (A) 41h
4 1 Dimension units Alpha (E/M) 45h or 4Dh
5 1 Weight units Alpha (E/M 45h or 4Dh
6 1 Factor units Alpha (D/I) 44h or 49h
7 4 Dimensional factor Numeric 0000-9999
11 6 Location ID Alpha 000000-ZZZZZZ
17 1 End of text Control (ETX) 03h
18 1 Carriage return Control (CR) 0Dh
19 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Units command Alpha (U) 55h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
