COMMUNICATIONS PROTOCOL Cubiscan 325 command set
CubiScan 325 Service Manual 58
Factor toggle
This command is used to set the dimensional factor to either domestic or international.
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Factor table command Alpha (f) 66h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
Command format
1 1 Start of text Control (STX) 02h
2 1 Fact. toggle command Alpha (F) 46h
3 1 Dom./Int'l Alpha (D/I) 44h or 49h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Fact. toggle command Alpha (F) 46h
3 1 Acknowledge Alpha (A) 41h
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Negative acknowledge format
1 1 Start of text Control (STX) 02h
2 1 Fact. toggle command Alpha (F) 46h
3 1 Neg. acknowledge Alpha (N) 4Eh
4 1 End of text Control (ETX) 03h
5 1 Carriage return Control (CR) 0Dh
6 1 Line feed Control (LF) 0Ah
Pos Len Description Type Range ASCII
