Pronto! 482/486/682/863 8-25
1 Put the cardboard core (3) on the rewind axle (2).
2 Feed the label strip over the guide axle (8) and under the roller (7) up to
the cardboard core (3).
3 Affix the end of the label strip with consideration of the selected
rewinding direction to the cardboard core using adhesive tape or label.
4 Slide the flange (5) with the knurled screw outward onto the rewind axle
until it stops.
5 Tighten the knurled screw (4) on the flange.
6 Switch on the rewinder on the power switch.
Note: Consider the required direction of rewinding:
• The broken line is valid for inside wound labels.
• The full line is valid for outside wound labels.
Note: When using small labels it is possible that the cardboard core not
covers the spring over the whole length. In this case the groove on the
flange must be aligned so that it fits on the spring of the rewind axle.
