QuickLabel Systems pronto! 486 - Placing the Unwinder

Pronto! 482/486/682/863 8-29
3 Flanges (2)
4 Winding Adapters (2)
5 Screws (8)
Placing the Unwinder
When you switch between outside and inside wound materials you have to
turn the unwinder 180 degrees. Compare the position of the swing arm (7) in
the two following figures.
Placing the unwinder for outside wound labels
