15-2 Memory media
Suitable Memory Media
External media
• Type 1 CompactFlash card up to a maximum size of 2 GB in the
corresponding card slot of the printer or in the external operating panel
• PC card (PCMCIA) in the corresponding card slot of the printer
• USB flash drive up to a maximum size of 2 GB at USB master interface
Internal medium
• Approximately 5 MB flash memory inside the printer (Internal Flash File
System)
Installation
1 Slide memory card contact-side first into the matching slot as far as it will
go. The rear section of the inserted memory card still extends from the
device housing so that it can be removed by hand.
or
Connect USB flash drive to an USB master interface.
2 Press the menu button.
3 Check whether the Memory card menu is shown in the display. If the
Memory card menu is not shown in the display, it could be because:
• the card slot being used is not selected as the default card slot
• the memory card is not inserted far enough into the card slot
• the memory card is entered incorrectly
Note: For external memory media only!
Note: When the memory cards are slid onto the contact pins, light
physical resistance can be felt.
Note: Do not remove a memory medium while it is being accessed. You
can configure the printer so that access to a memory medium is indicated
on the status line
