8-34 Accessories

Insertion of the Prepared Winding Axle

Unwinding from a roll with outside wound labels

Unwinding from a roll with inside wound labels

• Hang up the axle with material in the unwinder. When hanging up, the

flange with the knurled screw has to be in front.

• Feed the label strip (14) over the swing arm (7) and the rewind axle (15) to

the printer.

Note: Pay attention to the different positions of the unwinder. The position

depends on the winding of the material rolls as described in Placing the

Unwinder on page 8-29.
