1 Put the first rewind adapter (3) onto the rewind axle (4) and slide it up to
the disc (1) until it stops. Make sure that the knurled screw (2) of the
rewind adapter is led in the groove of the rewind axle.Tighten the
knurled screw (2).
2 Put the second rewind adapter (3) onto the rewind axle (4) and slide it
towards the first adapter until the clearance between the outer edge of it
and the disc (1) is a little less than the width of the cardboard core.
Tighten the knurled screw (2).
3 Put the cardboard core (5) on the rewind axle (2).
4 Feed the label strip over the guide axle (9) and under the roller (8) up to
the cardboard core (5).
5 Affix the end of the label strip with consideration of the selected
rewinding direction to the cardboard core using adhesive tape or label.
6 Slide the flange (7) with the knurled screw outward onto the rewind axle
until it stops.
7 Tighten the knurled screw (6) on the flange.
8 Switch on the rewinder on the power switch.
Note: Consider the required direction of rewinding:
• The broken line is valid for inside wound labels.
• The full line is valid for outside wound labels.
