Pronto! 482/486/682/863 10-13
• Press the feed key. For synchronization the media will be moved forward
and cut off. Synchronization is not necessary when the printhead was not
opened between print jobs, even if the printer was powered off between
print jobs.
• Remove the cuts from the table.
• Activate the cut mode in the software.
• For direct programming use the C-command (QuickLabel Pronto 482/
486/682/863 Programmer's Guide).
•Send a print job.
All labels in the job will be printed without stopping and be cut. With the
movement of the upper blade the labels will be pressed onto the stack (1)
and the table will be moved down little by little.
• When the table reaches the lower end position the print job will be
stopped and the error message Box full appears in the display of the
printer.
• After the end of the print job or when the error Box full occurs, remove
the stack from the table.
• After the error Box full resume the print job by pressing the pause key.
