12-6 Test functions
The Status print contains the following information:
Symbol Information
• Device type
• Version and creation date of the firmware
• Version and creation date of the system loader (bootloader)
Current values of selected local settings (see Local settings on
page 5-2).
Current values of selected device settings (see Device settings
on page 5-3).
Current values of selected print parameters (see Printing
parameters on page 5-5).
Current values of selected interface parameters (see Interfaces
on page 5-8).
Status of PIN activation (see Security on page 5-12).
•Operative time
• Number of labels printed
• Printed length with thermal transfer printing and thermal
direct printing
• Current measured values of the printhead temperature and
heat voltage
• Information on the working points of the label sensor
Line
pattern
The Status print presents lines differing in thickness at various
distances at the end. They are used to evaluate the print
quality.
