17-4 Specifications
External Rewinder (ER4)
Max. Material Width 120 mm (4.7 in)
Max. Rewind Diameter 210 mm (8.3 in)
Core Diameter 40 mm (1.6 in) on rewind axle
40 mm (1.6 in) on cardboard core
76 mm (3 in) on cardboard core
with adapter
Rewind Speed max 300 mm/s (12 in/s)
Label Rewinding Labels in- or outside
Operating Temperature 10 bis 35°C (50°F - 95°F) at 30 to 85%
humidity, non condensing
Storage- and Transport
Temperature
-20 bis 50°C (4°F - 122°F) at 10 to
85% humidity, non condensing
Dimensions of the Rewinder
Height
mm (in)
280 (11)
Width
mm (in)
260 (10,2)
Depth
mm (in)
270 (10.6)
Weight 5,0 kg (11 lb)
Operating Voltage 110 - 240 V~ / 50 - 60 Hz
