5-6 Configuration
Transfer print On for thermal transfer printing: Sensor for
monitoring the transfer ribbon is activated.
Off for thermal direct printing: Sensor for
monitoring the transfer ribbon is not
activated.
You can overwrite the setting for each print
job via software.
On
Warn level
ribbon
Warning via the Ethernet interface by way
of an SNMP message or e-mail sent when
the remaining diameter of the ribbon
supply roll undershoots the set value (32–74
mm).
Off
Label sensor Method for detecting the starting end of the
label.
Gap Sensor: Detection using changes in the
transparency between the label and label
gap.
Bottom-Reflect: Detection using reflex
marks on the bottom of the medium.
Continuos media: Synchronization of the
paper flow when using endless media in
cutting mode. More detailed information is
found in Chapter 9: CU4 Cutter Accessory.
Gap Sensor
Warn level
labels
Warning via the Ethernet interface by way
of an SNMP message or e-mail sent when
the remaining diameter of the label supply
roll undershoots the set value (45–300 mm).
Off
Tear-off mode Positioning the label medium for tearing off
at the tear-off plate.
On: Additional advancement of the label
medium which positions the label gap after
the last printed label at the dispense plate.
Off: Label advance stops once the last label
has fully passed the print line.
Off
Parameter Meaning Default
