-112-

Fault List SCC

Service 11

Indication Service 11

shown every time unit is

switched on

Water supply from

CDS to steam

generator leaking

Eliminate leak

Actual measured filling volume

above reference volume of steam

generator

Info

Check valve in the water

supply line to the steam

generator.

Valve working correctly?

yes

Change valve

Start volume measuring

by activating pumping

function,

first touch function- then

service- and finally key

for emptying steam

enerato

Level electrode clean,

cable and connector ok?

yes

Clean electrode,

change defective part

yes
