No. Designation Function
6 Section setting pre-selection Toggle key for alternating between 4 states
• Pre-selection of sections for changing the quantity,
see 4.7.3 +/- quantity
○ L: Left
○ R: Right
○ L+R: Left + right
• Section management (VariSpread function), see
2.4.3 Display of sections
7 Menu Switch between operating screen and main menu
8 ESC Canceling entries and/or returning to the previous menu
at the same time
9 Navigation field Four arrow keys and one Enter key for navigation
through menus and input fields
• Arrow keys for moving the cursor on the display or
for highlighting an input field
• Enter key to confirm an input
10 Function keys F1 to F4 Selection of the functions next to the function keys on the
display
11 Weighing/Trip count.
• Display of the remaining quantity in the hopper
• Trip counter
• kg left
• Meter counter
2. Layout and function
QUANTRON-A AXIS/MDS 5902662
13
