2.5 Library of icons used
The control unit QUANTRON-A displays icons for the individual menus and functions on the screen.
2.5.1 Operating screen icons
Icon Meaning
Quantity adjustment + (plus)
Quantity adjustment - (minus)
Quantity adjustment, left + (plus)
Quantity adjustment, left - (minus)
Quantity adjustment, right + (plus)
Quantity adjustment, right - (minus)
Manual quantity adjustment + (plus)
Manual quantity adjustment - (minus)
Left spreading side inactive
Left spreading side active
Right spreading side inactive
2. Layout and function
