Selecting a mode
u
Select the menu item System/Test > Mode.
u
Press the Enter key.
The display shows the current mode.
Press the Enter key to switch between the two modes.
4.10.4 Test/diagnosis
In the Test/diagnosis menu, you can check the functions of all actuators and sensors.
This menu is for information purposes only.
The list of sensors depends on the equipment of the machine.
CAUTION!
Risk of injury due to moving machine parts
During the tests, machine parts may move automatically.
▶
Before carrying out the tests, ensure that nobody is present in the danger zone of the
machine.
Sub-menu Meaning Description
Test points slider Test for approaching the various
position points of the metering slides
Calibration check
Metering slider Moving the left and right metering
slides
Example: metering slides
Voltage Checking the operating voltage
Level sensor Checking the level sensors
Weigh cell Checking the sensors
EMC sensors Checking the EMC sensors
Test points drop pt. Approaching the drop point Calibration check
LIN bus Checking the assemblies registered via
LIN bus
Example: LIN bus
TELIMAT sensor Checking the TELIMAT sensors
Sensor brd.spread Checking the sensors for the border
spreading unit
Example: GSE sensor
Hopper cover Checking the actuators
4. Operation
QUANTRON-A AXIS/MDS 5902662
77
