Example: LIN bus
u
Access the menu System/Test > Test/diagnosis
u
Select the LIN bus menu item.
u
Press the Enter key.
The status of the actuators/sensors is displayed.
Fig. 43: Test/diagnosis; example: LIN bus
[1] Status display
[2] Start self-test
[3] Connected equipment
LIN bus device status notification
The devices indicate various conditions:
• 0 = OK; no equipment error
• 2 = blockage
• 4 = overload
Example: GSE sensor
CAUTION!
Risk of injury due to moving machine parts
During the tests, machine parts may move automatically.
▶
Before carrying out the tests, ensure that nobody is present in the danger zone of the
machine.
4. Operation
QUANTRON-A AXIS/MDS 5902662
79
