4.13 Hopper cover
Only for AXIS (special equipment)
WARNING!
Danger of crushing and shearing due to externally-actuated components
The hopper cover will move without warning and can cause personal injury.
▶
Ensure that nobody is present in the hazard zone.
The AXIS EMC machine is equipped with an electrically operated hopper cover. During the refilling
process at the end of the field, you can open and close the hopper cover using the control unit and an
electrical drive.
The menu is only used for operating the actuators which open or close the hopper cover. The
machine control unit does not detect the exact position of the hopper cover.
Observe the movements of the hopper cover.
Fig. 46: Hopper cover menu
[1] Opening process display
[2] F4 function key: Close hopper cover
[3] Static display of the hopper cover
[4] F2 function key: Stop process
[5] F1 function key: Open hopper cover
4. Operation
84
5902662 QUANTRON-A AXIS/MDS
