Access the menu Main menu > Fast emptying.
CAUTION!
Risk of injury due to automatic adjustment of the drop point
With AXIS EMC, the Approach drop point Yes = Start alarm message appears. When you
press the Start/Stop function key, the drop point automatically moves to position 0. After the
calibration, the drop point automatically moves to the preset value again. This may cause
injury and property damages.
▶
Before pressing the Start/Stop key, ensure that nobody is present in the hazard zone of
the machine.
Fig. 35: Fast emptying menu
[1] Metering slide opening display
[2] Icon for fast emptying (here: left side
selected, not started)
[3] Fast emptying of right section (here: not
selected)
[4] Fast emptying of the left section (here:
selected)
u
Press the function key to select the section for which the fast emptying function is to be carried
out.
The selected section is shown as an icon in the display.
u
Press Start/Stop.
The fast emptying process starts.
u
Press Start/Stop when the hopper is empty.
Fast emptying is complete.
With machines equipped with electrical drop point actuators, the Approach drop point Yes = Start
alarm message is activated.
4. Operation
68
5902662 QUANTRON-A AXIS/MDS
