3-8 Raychart 425 Chartplotter
➤ To delete a waypoint using the waypoint list:
1. Select the waypoint from the waypoint list as previously described.
The waypoint list function bar is displayed.
2. Use trackpad up/down to move through the list to highlight the
required waypoint.
3. Select
ERASE WAYPOINT. Press ENTER to erase the waypoint.
To return to chart mode, press CLEAR three times.
Moving Waypoints
Any waypoint, except the target waypoint, can be moved. The Waypoint
function bar and cursor are used to move the selected waypoint, or the
waypoint position can be edited.
Note: Take care when editing waypoints as it is possible to move way-
points that are used in routes stored in the Route Database List.
➤ To move a waypoint using the cursor:
1. Place the cursor over the waypoint; see Selecting a Waypoint on
page 3-4.
2. Select
WAYPOINT OPTIONS and press ENTER to display the Edit Way-
point function bar.
3. Select
MOVE WAYPOINT. The selected (highlighted) function now has
help text appended to it (Figure 3-15):
Figure 3-15: Move Waypoint Function
4. Move the cursor to the required waypoint position.
5. When the cursor is in the correct position, press
ENTER to set the new
position and return to normal cursor control.
To return to chart mode, press CLEAR.
➤ To move a waypoint using the Waypoint List:
1. Select the waypoint using the Waypoint List as described above. The
waypoint functions are displayed.
2. To edit the waypoint position proceed as previously described in
Editing Waypoint Details on page 3-5.
CURSOR SELECT POS, "ENTER"
MOVES WPT, "CLEAR" TO QUIT
