3-30 Raychart 425 Chartplotter
3.6 Transferring Waypoints and Routes
Displayed Waypoints
Waypoints and routes can be received and transmitted via NMEA, see
also Chapter 5, Section 5.4, Installing the Chartplotter. The NMEA link
could be to a PC, typically via a spare RS232 COM port.
Managing Database Lists
The SEND WAYPOINTS function sends all waypoints in the Waypoint List
and all routes in the Route List. Sending the Waypoint List does not affect
current routes.
Note: Sending the Waypoint List includes waypoints in an unsaved route.
The
RECEIVE WAYPOINTS function adds waypoints and routes received
via NMEA to the Waypoint List and Route List.
Note: Where multiple waypoints have the same position, the last way-
point sent is the only one included in the Waypoint List.
➤ To send waypoints (and route lists):
1. From chart mode, press
ENTER; the primary function bar is displayed
(Figure 3-46):
Figure 3-46: Primary Function Bar
2. Using trackpad left/right, select WAYPOINTS (Figure 3-47).
Figure 3-47: Waypoint Function Bar
3. Select WAYPOINT LIST.
The Waypoint List is displayed, with its associated function bar
(Figure 3-48):
Figure 3-48: Waypoint List Function Bar
4. Initiate receiving of waypoints on the NMEA compatible equipment.
5. Select
WPT/ROUTE TRANSFER.
