3-26 Raychart 425 Chartplotter
The graphical XTE indication will place arrows either side of the steering
instruction and pointing towards it dependent on the difference between
COG and bearing to Waypoint. The first arrow is shown when the
difference reaches 5° and thereafter at 5° intervals.
Waypoint Data
The Waypoint Data display comprises text data occupying the whole
screen (Figure 3-42).
Figure 3-42: Waypoint Data Display
If a route is not selected, the ROUTE field displays NO ROUTE.
The
WAYPOINT field shows the name of the waypoint. If the waypoint is
part of a route then the title field includes the waypoint index in the route.
If there is no target waypoint the text indicates
NO WAYPOINT and all
waypoint data is shown as dashes, one per character. If a route is being
followed and the waypoint is not named, the text shows the waypoint
number within the route (as displayed on screen). If a
GOTO Cursor or
Port is in progress, the text indicates
GOTO CURSOR or GOTO ‘Port Name’.
BRG, RNG and XTE data relate to the target waypoint.
Time refers to time data which is acquired from GPS information. Any
local time offset is set in the System Set Up menu, see Chapter 4.
D4702_1
COG 230° T TIME 13:29 12/12/99
SOG 6.8 Kts TTG 01:03
XTE 0.5 nm ETA 14:32 12/12/99
BRG 234° T
RNG 12.4 nm
ROUTE
ROUTE 01
WPT 001
WAYPOINT
STEER STARBOARD
