3-20 Raychart 425 Chartplotter
➤ To restart XTE:
1. Press the
GOTO key.
If following a route, the following functions are displayed
(Figure 3-32):
Figure 3-32: GOTO Options (1)
If a GOTO is in progress, the following functions are displayed
(Figure 3-33):
Figure 3-33: GOTO Options (2)
2. Select RESTART XTE. The dotted line between the original origin and
the target waypoint is redrawn from the vessel’s current position to
the target waypoint and the XTE is reset to zero
Going to an Individual Target
Rather than following a route, you can go directly to a selected target.
This can be an existing waypoint, a port or nearest facility or the current
cursor position.
Go to a Waypoint
➤ To navigate directly to an existing waypoint:
1. From the normal chart display either:
i. Use the trackpad to position the cursor over the required waypoint
until the waypoint options function is displayed (Figure 3-34):
Figure 3-34: Waypoint Options
...then press ENTER to display the waypoint functions (Figure 3-35):
Figure 3-35: Waypoint Functions
D4688_1
STOP
FOLLOW
RESTART
XTE
WAYPOINT
ADVANCE
D4689_1
STOP
GOTO
RESTART
XTE
