Chapter 4: Setting Up 4-3
Bearing Mode
The mode (MAGnetic or TRUE) of all bearing and heading data displayed.
This is indicated by
M or T in the BRG or COG field of the Chart status bar.
Key Beep
This setting controls audible feedback resulting from operation of the
keys.
Note: Alarms remain active.
Units
This sets the units for distance, speed and depth. This setting will be used
to display all data. However, the distance units do not affect the chart
scale, which is always in nautical miles.
Variation
The variation value is the difference between True and Magnetic
direction data for heading or bearing values. The Magnetic value is
derived from True by applying the user selected value of variation.
The variation is varied in 1° steps to 30° East or West. Press trackpad right
to move the value eastward, or left to move it westward. The selected
value is retained when the unit is switched off. The Default value is zero.
DEPTH UNITS METRES
FEET
FATHOMS
METRES
VARIATION 30°W to 30°E (1° steps) 0.0°E
DATE FORMAT DD/MM/YY or MM/DD/YY DD/MM/YY
TIME OFFSET UTC or local offset value
up to 13 hours in 1 hour
steps
UTC
LANGUAGE Multi Language ENGLISH
SIMULATOR OFF/ON OFF
SIMULATED
SOG
00Kt to 99Kt in 1Kt steps 00Kt
SIMULATED
COG
000° to 359° in 1° steps 000°
Table 4-2: System Menu Options (Continued)
Menu Item Options
Factory
Default New Setting
