1-6 Raychart 425 Chartplotter
Display Options
Display options are selected in System Set Up and Chart Set Up as
described in Chapter 4.
Operating Controls
The chartplotter is operated by means of the following controls:
• A trackpad.
• Six dedicated push-button (labelled) keys.
• Function bar which changes according to the selected operation.
• On-screen pop-up menus from which options are selected.
• On-screen database lists which enable the editing of items.
The controls are shown in Figure 1-3; they are back-lit for night-time use.
Figure 1-3: Raychart 425 Chartplotter Operating Controls
PAG E
GOTO
MOB
CLEAR
ENTER
TOPSHAM
EXETER
TEIGNMOUTH
EXMOUTH
TORQUAY
DARTMOUTH
PLYMOUTH
ENPORT
SALCOMBE
PORTLAND
HARBOUR
ISLE O
CAP DE
LA HAGUE
ALDERNEY
GUERNSEY
JERSEY
PORTB
CSR 48°30.367'N
POS 1°35.636'W
128 nm
FIND SHIP ROUTES WAYPOINTS
BRG 231°T
RNG 40.91nm
SIM NU
GOTO key
PAGE key
CLEAR key
RANGE key
ENTER key
Trackpad
POWER key
Navionics
®
Nav-Chart
compartment
Cursor
Primary
Function Bar
Status Bar
D4982_3
