Chapter 3: Operation 3-33
Figure 3-52: Track Interval Setting Guide
➤ To set up a track:
1. Select the
INTERVAL function.
Use trackpad up/down to select the appropriate options to set either a
time interval or a distance interval; press up to increase the interval or
down to decrease the interval.
2. Use trackpad left/right to select
TRACK ON and press ENTER.
The
TRACK ON text changes to indicate TRACK OFF.
The vessel’s track is displayed on-screen with a line joining the points at
the selected interval.
Clearing the Current Track
The current track can be cleared from the screen.
➤ To clear the current track:
1. Select
CLEAR TRACK.
The current track is cleared from the screen and memory.
2. If no further track points are to be placed, select
TRACK OFF and press
ENTER; the TRACK OFF text changes to indicate TRACK ON.
33 min
5 hrs, 30 min
16 hrs, 40 min
33 hrs, 20 min
13 days, 21 hrs, 20 min
41 days, 16 hrs
100 nm
200 nm
1000 nm
2000 nm
TRACK TIME
TRACK DISTANCE
1 s
10 s
30 s
1 min
10 min
30 min
0.05 nm
0.1 nm
0.5 nm
1.0 nm
TRACK INTERVAL SETTING
D4971_1
