Reer MOSAIC Master M1 User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
16 8540780 • 30/03/2016 • Rev.26
English
-
24VDC power supply
-
Input
Node selection
Input ( according to EN 61131-2 )
Input
Input ( according to EN 61131-2 )
-
0VDC power supply
-
Input
Digital input 1
Input according to EN 61131-2
Input
Digital input 2
Input according to EN 61131-2
Input
Digital input 3
Input according to EN 61131-2
Input
Digital input 4
Input according to EN 61131-2
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Input
Digital input 5
Input according to EN 61131-2
Input
Digital input 6
Input according to EN 61131-2
Input
Digital input 7
Input according to EN 61131-2
Input
Digital input 8
Input according to EN 61131-2
Table 3
-
24VDC power supply
-
Input
Node selection
Input ( according to EN 61131-2 )
Input
Input ( according to EN 61131-2 )
-
0VDC power supply
-
Input
Digital input 1
Input according to EN 61131-2
Input
Digital input 2
Input according to EN 61131-2
Input
Digital input 3
Input according to EN 61131-2
Input
Digital input 4
Input according to EN 61131-2
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Input
Digital input 5
Input according to EN 61131-2
Input
Digital input 6
Input according to EN 61131-2
Input
Digital input 7
Input according to EN 61131-2
Input
Digital input 8
Input according to EN 61131-2
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Output
Short circuit detected output
PNP active high
Input
Digital input 9
Input according to EN 61131-2
Input
Digital input 10
Input according to EN 61131-2
Input
Digital input 11
Input according to EN 61131-2
Input
Digital input 12
Input according to EN 61131-2
Table 4
