MANUAL – REFLEX EZ-TRAC™ | 28
7.6.5 Orientation equipment
Part numbers for the orientation equipment.
Item no. Item Part no.
19. Orientation mule shoe 3100030
20. Orientation bull plug for Reflex EZ-Trac 2210003
21. Lead tell tale, set of 6 3100043
22. Mule shoe sleeve
BQ box – pin 3100044
NQ box – pin 3100045
HQ box – pin 3100047
7.7 Equipment overview
An overview of all REFLEX EZ-TRAC™ equipment is shown in the
figures below.
The item numbers are the same as in the previous sections and
figures.
Figure 7 Instrument
1.
2. 3. 4.
Figure 8 Control unit
5.
Figure 9 Utilities
10. 11. 12.
