MANUAL – REFLEX EZ-TRAC™ | 58
Figure 67 Initialise instrument
Initialise instrument
1. Remove the top coupling from the REFLEX EZ-TRAC™ and direct
the IR port of the
REFLEX™ EZ-COM unit towards the IR port of the
instrument.
2. Select INIT to initialise the instrument.
3. Do not break the IR connection until ‘Ready to survey’ is
displayed.
4. Thread the top coupling onto the instrument.
9.6 Assemble survey system
Assemble the survey system with running gear appropriate for the
chosen surveying method.
Instructions for how to assemble the survey system are provided in
the chapter Surveying Methods.
9.7 Execute survey
Position the instrument at the survey station and register the
measurement.
9.7.1 Single Shot execution
Figure 68 Single Shot execution
Execute Single Shot survey
1. Position the survey system at the survey station, using one of the
methods described in chapter Surveying Methods.
2. When the instrument is stationary at the survey station, select
MEASURE on the REFLEX™ EZ-COM unit.
3. Do not move the instrument while ‘Measuring’ is displayed.
