MANUAL – REFLEX EZ-TRAC™ | 33
Figure 17 USB connector
8.1.5 Software version
When the REFLEX™ EZ-COM unit is turned on, the software version is
displayed under the
REFLEX™ logo.
In the figure below, the software version is 1.0.0.
Figure 18 Version number
8.2 Main Menu
The MAIN menu is displayed at start up a short while after the
REFLEX™ logo is shown. The MAIN menu gives access to the
SURVEY, RESULTS and SETTINGS menus.
Figure 19 MAIN menu
Survey The SURVEY menu gives access to the Single Shot, Multi Shot and
Orientation surveying functions.
Results The RESULTS menu gives access to all stored Single Shot, Multi
Shot and Orientation surveys.
Settings The SETTINGS menu gives access to the settings functionality;
Units, Magnetic Reference, Time & Date and License Key.
UP/DOWN Use the UP/DOWN keys to navigate between the menu options.
OK Use the OK key to select the active option.
USB
