Regal 3760 - If the Motor Stops Suddenly; Replacing Exhaust Filter

208
Chapter 7
Note:
If the motor stops the thermal protector on the unit will
reset automatically after about 1/2 hour. This is normal
for the vacuum cleaner.
If The Motor Stops Suddenly:
1. The most common cause is a clogged hose. Try to un-
clog the hose with a long object or by shaking the hose
until the debris falls out.
2. The bag is overfilled and fine dust has clogged the bag.
3. The vacuum cleaning tools are clogged.
4. The motor (exhaust) filter is dirty and should be cleaned
or replaced.
5. While the vacuum cleaner is being used keep the cush-
ion up to provide additional air to the unit. This will help
the unit from shutting down.
Replacing Exhaust Filter
To Remove
Pinch Filter In
The Middle &
Pull Out
To Replace:
Pinch In The
Middle & Slide
In One Side First
