36
Chapter 9
SIRIUS MARINE WEATHER
LED STATUS
The LED on the connector panel provides valuable
troubleshooting information on the status of your
weather system.
The LED blinks green while the system is operating
normally.. If the unit detects a problem, the LED blinks
amber to indicate a warning or red to indicate an error.
The pattern ot the LED blink is a code representing the
nature of the problem. For multiple warnings/errors the
codes are given in sequence with a 1.5 second pause
between the indications.
It is normal during the first minute of initial power that
the SR100 status LED shows no activity and remains
off. During the second minute the status LED will start
to flash the amber or red fault strings. Typically, during
normal operation, a flashing green LED will occur within
90 seconds of initial power. If there is no LED indicaiton
of any sort displayed after 90 seconds you should check
the circuit breaker.
A blinking red LED indicates an internal fault condition.
If this condition persists contact the Raymarine Technical
Services.
The following table shows the LED status codes and their
meanings:
DEL
ROLOC
DEL
NRETTAP
NOITPIRCSED
NEERGGNIKNILB
LAMRON
NOITAREPO
REBMA
NOCES1
FFOCES1
ANNETNA
DEKOOHNU
REBMA
NOCES1
FFOCES1
NOCES1
FFOCES1
KLATAES
ELBAC
DEKOOHNU
DERGNIKNILB
LANRETNI
TLUAF
