Technical Information
12-8
MID BERTH LIGHTS
WHERE PENETRATED BY HARNESS.
3. SEAL FIRE WALL BULKHEAD
AS NEEDED.
2. INSTALL CHAFE PROTECTION
A MAXIMUM OF EVERY 18 INCHES.
1. HARNESS TO BE SECURED
NOTES:
FIRE WALL BULKHEAD
12 VDC MAIN DISTRIBUTION PANEL
110/60HZ OR 220/50HZ VAC AND
SHOWER PUMP
STEREO MEMORY/
BATTERY CHARGER
WASTE PUMP
VACFLUSH
MAIN GROUND BUSS
WATER HEATER
BILGE BLOWER
READING LIGHT
READING LIGHT
CO MONITOR/
REV. DATE:DR. BY: APP. BY:
2300 JETPORT DRIVE
ORLANDO FLORIDA 32809-7895
TELEPHONE (407) 851-4360
SCALE:
DWG. NO.:
LATEST REV LET:
APP. BY:
ETA22B
REGAL MARINE INDUSTRIES
DATE:
DR. BY:
DRAWING TITLE:
REVISION DESCRIPTION
3760 SUMP/MDP HARNESS
01-27-03
To Next Page
