20
Chapter 4
TO PREVENT POSSIBLE TRANSMISSION
DAMAGE SHIFT IN AND OUT OF GEAR AT
IDLE SPEEDS ONLY.
NOTICE
TO PREVENT POSSIBLE BODILY INJURY
AND PROPERTY DAMAGE
DO NOT ATTEMPT TO ADJUST SHIFT OR
THROTTLE CONTROLS.
CONSULT A MARINE PROFESSIONAL.
WARNING
!
REMOTE CONTROL OVERVIEW
Regal features separate binnacle style remote controls on
the 3760 V-drive. The port (left) remote control handles
operate the engine shift positions. The shift controls can
also be identified by the black inserts on the control
handles. See illustration A.
The port shift handle controls the port engine.
The starboard shift handle controls the starboard engine.
SHOWN AT
MINIMUM THROTTLE
THROTTLE CONTROLS
The starboard (right) remote control handles operate the
starboard engine throttle controls. The throttle controls
can also be identified by the red inserts on the control
handles. See illustration B.
The port throttle handle controls the port engine.
The starboard throttle handle controls the starboard
engine.
PORT
THROTTLE
STBD.
THROTTLE
B
SHIFT CONTROLS
IN NEUTRAL POSITION
PORT
SHIFT CONTROL
STARBOARD
SHIFT CONTROL
N
A
PRACTICE YOUR REMOTE CONTROL
SHIFTING AT AN ON THE WATER
ENVIRONMENT WITHOUT HEAVY
BOAT TRAFFIC.
NOTICE
