Renault F4R - Page 119

10A-113
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine/gearbox assembly: Removal - Refitting
K9K, and 830 or 832
10A
Essential special tooling
Mot. 1448 Long nose pliers for hose
clips.
Mot. 1202-02 Pliers for small hose clips.
Ms. 583 Hose clamp pliers.
Mot. 1390 Support for removing/refitting
the engine - gearbox assem-
bly.
Mot. 1453 Multiple-adjusting engine
mounting support with retai-
ning straps.
Mot. 1453-01 Additional winder nut on
engine lift support Mot. 1453.
Essential equipment
refrigerant charging station
safety strap(s)
Tightening tor
quesm
bolt of the left-hand sus-
pended engine moun-
ting support on the
gearbox
62 N.m
bolts of the "rubber pad
- cover" assembly of the
right-hand suspended
engine mounting on the
cylinder head
62 N.m
bolts of the "rubber pad
- cover" assembly of the
right-hand suspended
engine mounting on the
body
62 N.m
upper engine tie-bar bolt
on the engine
115 N.m
upper engine tie-bar bolt
on the body
105 N.m
bolt of the "dehydrator
reservoir - compressor"
connecting pipe on the
compressor
8 N.m
earth cable nut on the
body
8 N.m
connecting pipe bolts on
the condenser
8 N.m
air filter unit air outlet
pipe clip on the turbo-
charger
5.5 N.m
lower engine tie-bar bolt
on the subframe
180 N.m
lower engine tie-bar bolt
on the lower engine tie-
bar support
180 N.m
IMPORTANT
Wear leaktight gloves (Nitrile type) for this opera-
tion.
WARNING
To prevent impurities from entering the circuit, place
protective plugs on all fuel circuit components
exposed to the open air.
WARNING
To avoid any corrosion or damage, protect the
areas on which fuel is likely to run.
WARNING
Keep the pipe unions away from contaminated
areas.
WARNING
To prevent moisture from entering the system,
place plugs on the cold loop components which are
open to the air.
WARNING
To avoid any leaks, check that the pipe surface is
sound before positioning the new seal. The surface
must be clean and scratch free.
Tightening torquesm
