10A-131
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine/gearbox assembly: Removal - Refitting
K9K, and 830 or 832
10A
a Refit the lower engine tie-bar.
a Tighten to torque:
-the lower engine tie-bar bolt on the subframe
(180 N.m),
-the lower engine tie-bar bolt on the lower engi-
ne tie-bar support (180 N.m).
a Refit the lower engine tie-bar (see 19D, Engine
mounting, Lower engine tie-bar: Removal - Refit-
ting, page 19D-33) .
a Refit:
-the new differential output seals (see Differential
output seal: Removal - Refitting) (21A, Manual
gearbox),
-the front left-hand wheel driveshaft (see Front left-
hand wheel driveshaft: Removal - Refitting)
(29A, Driveshafts),
-the front right-hand wheel driveshaft (see Front ri-
ght-hand wheel driveshaft: Removal - Refitting)
(29A, Driveshafts).
a Refill:
-the engine oil (if necessary) (see 10A, Engine and
cylinder block assembly, Engine oil: Draining -
Refilling, page 10A-40) ,
-the cooling circuit (see 19A, Cooling, Cooling cir-
cuit: Draining - Refilling, page 19A-17) ,
-the manual gearbox (see Manual gearbox oil:
Draining - Refilling) (21A, Manual gearbox),
-the refrigerant circuit using a refrigerant charging
station (see Coolant circuit Draining - Refilling)
(62A, Air conditioning).
a Refit:
-the engine undertray,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
-the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
- the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
- the battery (see Battery : Removal - Refitting)
(80A, Battery),
- the engine cover.
a Adjust the headlight beams (see Front headlight:
Adjusting) (80B, Headlights).
K9K, and 832
K9K, and 830
