Renault F4R - Page 154

10A-148
ENGINE AND CYLINDER BLOCK ASSEMBLY
Engine/gearbox assembly: Removal - Refitting
F4R
10A
a Separate the following on the radiator:
-the expansion bottle top cooling hose clip (Mot.
1448) using the tool (11) ,
-the bottom cooling hose clip (12) using the tool
(Mot. 1448).
a Disconnect:
-the expansion bottle top cooling hose,
-the radiator bottom cooling hose.
a Unclip from the front end panel:
-the wiring at (13) ,
- the expansion bottle top cooling hose.
a Remove the bolts (14) from the fan assembly wiring
channel.
a Remove:
- the front end panel clips (15) ,
- the front end panel upper bolts (16) .
135954
135511
135736
135719
