11A-8
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
K4M
11A
a Tighten to torque the tensioning roller bolt (40
N.m).
a Turn the accessories belt tensioning roller clockwise
using a 16 mm spanner.
a Lock the tensioning roller using a 6 mm Allen key.
a Refit a new accessories belt.
a Retrieve the 6 mm Allen key and gradually release
the tensioning roller using a 16 mm spanner.
a Rotate the crankshaft clockwise twice to balance the
accessories belt tension on every pulley.
III - FINAL OPERATION
a Refit:
-the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
