11A-10
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
K9K
11A
REFITTING
I - REFITTING PREPARATION OPERATION
a
a Use a brush to remove any deposits from the
crankshaft accessories pulley V grooves.
a parts always to be replaced: Accessories belt
(10,10,01,03).
a parts always to be replaced: Accessories belt
tensioning roller (10,10,01,04).
a parts always to be replaced: Accessories tensio-
ning roller bolt (10,10,01,09).
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit a new accessories belt tensioning roller.
a Torque tighten the new accessories belt tensio-
ning roller bolt (40 N.m).
a Refit a new accessories belt.
a Rotate the crankshaft clockwise through two revolu-
tions (timing end).
III - FINAL OPERATION
a Refit:
-the engine undertray,
-the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
WARNING
Only use brushes with plastic or non-corrosive
metal (brass) bristles.
