11A-12
TOP AND FRONT OF ENGINE
Accessories belt: Removal - Refitting
F4R
11A
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Accessories belt
(10,10,01,03).
a parts always to be replaced: Accessories belt
tensioning roller (10,10,01,04).
a Use a brush to remove any deposits from the
crankshaft accessories pulley V-grooves.
II - REFITTING OPERATION FOR PARTS
CONCERNED
a Refit:
-a new accessories belt tensioning roller,
-a new accessories belt tensioning roller bolt.
a Torque tighten the accessories belt tensioning
roller bolt (50 N.m).
a Turn the accessories belt tensioning roller clockwise
using a 16 mm spanner.
a Refit a new accessories belt.
a Rotate the crankshaft clockwise twice to balance the
accessories belt tension on every pulley.
III - FINAL OPERATION
a Refit:
-the engine undertray,
-the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres).
WARNING
Only use brushes with plastic or non-corrosive
metal (brass) bristles.
