11A-28
TOP AND FRONT OF ENGINE
Crankshaft accessories pulley: Removal - Refitting
F9Q
11A
REFITTING
I - REFITTING PREPARATION OPERATION
a parts always to be replaced: Crankshaft acces-
sories pulley bolts (10,03,03,10).
a Clean the crankshaft accessories pulley V grooves
using a brush with non abrasive bristles if it is to
be reused.
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit the crankshaft accessories pulley.
a Lock the flywheel using a 30 torx screwdriver.
a Torque tighten the crankshaft accessories pulley
bolt (40 N.m + 110˚ +/- 10˚).
III - FINAL OPERATION
a Refit:
-the protective plate,
-the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
-the front right-hand wheel arch liner (see Front
wheel arch liner: Removal - Refitting) (55A, Ex-
terior protection),
-the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
-the engine undertray.
Note:
Only replace the crankshaft accessories pulley
during general maintenance operations.
