11A-82
TOP AND FRONT OF ENGINE
Timing belt: Removal - Refitting
K4M
11A
a Fit the camshaft pulley locking tool (Mot. 1490-01)
(54) (use the bolt and nut of the upper timing cover
to fit the (Mot. 1490-01)) using the (Mot. 799-01) if
necessary.
a Fit the camshaft pulley locking tool (Mot. 1490-01)
(55) (use the bolt and nut of the upper timing cover
to fit the (Mot. 1490-01)) using the (Mot. 799-01) if
necessary.
K4M, and 848
135898
K4M, and 858 or 866
136524
