11A-101
TOP AND FRONT OF ENGINE
Rocker cover: Removal - Refitting
K4M
11A
a Refit:
-the camshaft dephaser,
-a new bolt on the camshaft dephaser,
-the exhaust camshaft sprocket,
-a new nut on the exhaust camshaft sprocket,
a Position the tool (Mot. 1490-01) on the camshaft
sprockets.
a Torque tighten the new nut on the exhaust cams-
haft sprocket (30 N.m + 84˚ ±±
±±
4˚).
a Torque tighten the new nut on the inlet camshaft
sprocket (30 N.m + 84˚ ±±
±±
4˚).
a Torque tighten the new bolt on the camshaft de-
phaser (100 N.m).
a Refit the camshaft dephaser blanking cover.
a Remove the tool (Mot. 1490-01) from the camshaft
sprockets.
a Refit:
-the camshaft position sensor (see 17B, Petrol in-
jection, Camshaft position sensor: Removal -
Refitting, page 17B-13) ,
-the camshaft dephaser solenoid valve (see 11A,
Top and front of engine, Camshaft dephaser
solenoid valve: Removal - Refitting, page 11A-
184) .
a Refit:
-the oil separator (see 11A, Top and front of engi-
ne, Oil decanter: Removal - Refitting, page 11A-
205) ,
- the ignition coils (see 17A, Ignition, Coils Remo-
val - Refitting, page 17A-1) ,
- the inlet manifold (see 12A, Fuel mixture, Inlet
manifold: Removal - Refitting, page 12A-23) ,
- the timing belt (see 11A, Top and front of engine,
Timing belt: Removal - Refitting, page 11A-29) ,
- the crankshaft accessories pulley (see 11A, Top
and front of engine, Crankshaft accessories
pulley: Removal - Refitting, page 11A-15) ,
- the right-hand suspended engine mounting (see
19D, Engine mounting, Right-hand suspended
engine mounting: Removal - Refitting, page
19D-18) ,
- the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
- the lower engine tie-bar (see 19D, Engine moun-
ting, Lower engine tie-bar: Removal - Refitting,
page 19D-33) ,
- the engine undertray,
- the front section of the front right-hand wheel arch
liner (see Front wheel arch liner: Removal - Re-
fitting) (55A, Exterior protection),
- the front right-hand wheel (see Wheel: Removal -
Refitting) (35A, Wheels and tyres),
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
- the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing)
- the throttle valve (see 12A, Fuel mixture, Throttle
valve: Removal - Refitting, page 12A-17) ,
- the engine cover.
a Connect the battery (see Battery: Removal - Refit-
ting) (80A, Battery).
K4M, and 858 or 866
K4M, and 848
K4M, and 858 or 866
K4M, and 858 or 866
