11A-152
TOP AND FRONT OF ENGINE
Cylinder head: Removal - Refitting
K9K
11A
a Refit:
-the support of the injector rail protector cover,
-the injector rail protector cover.
a Clip on the injector rail protector cover.
a Refit:
-the oil vapour rebreathing valve seal on oil vapour
rebreathing valve,
-the oil vapour rebreathing valve.
a Connect the brake servo pipe union to the vacuum
pump.
a Refit the bracket of the oil vapour rebreathing valve.
a Fit the breather support onto the gearbox.
a Refit the breather support nut on the gearbox.
a Connect the oil vapour rebreathing pipe on the oil
vapour rebreathing valve.
a Fit the oil vapour rebreathing pipe clip on the oil va-
pour rebreathing valve.
a Connect the oil vapour rebreathing pipe union to the
air filter unit air outlet pipe.
a Refit the damper valve (see 12A, Fuel mixture, Air
inlet flap: Removal - Refitting, page 12A-11) .
a Refit:
-the intercooler air outlet pipe (see 12B, Turbo-
charging, Intercooler air outlet pipe: Removal -
Refitting, page 12B-56) ,
-the turbocharger air outlet pipe (see 12B, Turbo-
charging, Intercooler air inlet pipe: Removal -
Refitting, page 12B-41) ,
-the timing belt (see 11A, Top and front of engine,
Timing belt: Removal - Refitting, page 11A-29) .
a Refit the camshaft position sensor (see 13B, Diesel
injection, Camshaft position sensor: Removal -
Refitting, page 13B-19) .
a Refit:
- the right-hand suspended engine mounting (see
19D, Engine mounting, Right-hand suspended
engine mounting: Removal - Refitting, page
19D-18) ,
- the scoop under the scuttle panel grille (see Scoop
under scuttle panel grille: Removal - Refitting)
(56A, Exterior equipment),
- the scuttle panel grille (see Scuttle panel grille:
Removal - Refitting) (56A, Exterior equipment),
-the windscreen wiper arms (see Windscreen wi-
per arm: Removal - Refitting) (85A, Wiping -
Washing),
- the accessories belt (see 11A, Top and front of
engine, Accessories belt: Removal - Refitting,
page 11A-7) ,
- the turbocharger oil return pipe (see 12B, Turbo-
charging, Turbocharger oil pipe: Removal - Re-
fitting, page 12B-22) ,
- the catalytic converter (see 19B, Exhaust, Cataly-
tic converter: Removal - Refitting, page 19B-17)
,
-the front bumper (see Front bumper: Removal -
Refitting) (55A, Exterior protection),
- the engine undertray,
- the front section of the front wheel arch liners (see
Front wheel arch liner: Removal - Refitting)
(55A, Exterior protection),
- the front wheels (see Wheel: Removal - Refitting)
(35A, Wheels and tyres),
- the engine cover.
a Connect the battery (see Battery : Removal - Refit-
ting) (80A, Battery).
K9K, and 830
K9K, and 832
K9K, and 830
