11A-208
TOP AND FRONT OF ENGINE
Oil decanter: Removal - Refitting
F9Q
11A
REMOVAL
I - REMOVAL PREPARATION OPERATION
a Position the vehicle on a two-post lift (see Vehicle:
Towing and lifting) (02A, Lifting equipment).
a Remove:
-the engine cover,
-the engine undertray bolts,
-the engine undertray.
II - OPERATION FOR REMOVAL OF PART
CONCERNED
a Remove the dipstick (1) .
a Disconnect the oil vapour rebreathing pipe (2) .
a Disconnect the oil return pipes (3) .
a Remove the oil separator bolts (4) .
a Separate the oil separator clip on the cylinder block
using the tool (Mot. 1448).
a Remove the oil separator.
Essential special tooling
Mot. 1448 Long nose pliers for hose
clips.
Tightening torquesm
oil separator bolts 30 N.m
133990
137191
137192
