12A-6
FUEL MIXTURE
Air filter unit: Removal - Refitting
12A
-the « air filter unit - air filter - air sleeve » assembly
(6) ,
-the air sleeve of the « air filter unit - air filter - air
sleeve » assembly.
If replacing the air filter unit
a Remove the air flowmeter (see 12A, Fuel mixture,
Air flowmeter: Removal - Refitting, page 12A-7) .
REFITTING
I - REFITTING PREPARATION OPERATION
a Refit the air flowmeter (see 12A, Fuel mixture, Air
flowmeter: Removal - Refitting, page 12A-7) .
II - REFITTING OPERATION FOR PART
CONCERNED
a Refit:
-the air sleeve to the « air filter unit - air filter - air
sleeve » assembly,
-the « air filter unit - air filter - air sleeve » assembly,
-the air filter unit bolts.
a Torque tighten the air filter unit bolts (8 N.m).
a Connect the air flowmeter connector.
a Clip the connector onto the scuttle panel grille.
a Connect the air outlet pipe of the air filter unit.
a Torque tighten the air filter unit air outlet pipe clip
(6 N.m).
a Refit the battery tray (see Battery tray: Removal -
Refitting) (80A, Battery).
a Refit the battery (see Battery: Removal - Refitting)
(80A, Battery).
F9Q or K9K
F9Q or K9K
F9Q or K9K
