14A-23
ANTIPOLLUTION
Exhaust gas recirculation assembly: Removal - Refitting
K9K
14A
a Undo the air filter unit air outlet pipe clip (17) from
the turbocharger.
a Undo the air filter unit air outlet pipe clip (18) from
the turbocharger.
a Disconnect the air filter unit air outlet pipe from the
turbocharger.
a Remove the air outlet pipe from the air filter box.
a Unclip the hose of the turbocharging pressure regu-
lation solenoid valve from the exhaust gas cooler co-
ver.
K9K, and 832
135410
K9K, and 830
136639
